Sliding Window

Sliding Window

Maximum View – Unlimited Possibilities

The View-Max® window offers unparallel levels of flexibility by allowing designers and architects the choice of 76mm (Derwent) or 101.6mm (McArthur) framing to cater for both the slimline applications and those of a more robust commercial design.

The View-Max® window offers the flexibility of single and double glazing options. The View-Max® integrates a number of design initiatives unique to Alspec® such as the proprietary locking, roller and drainage systems.

Developed specifically for multi-storey residential and architecturally designed housing View-Max® windows offer superior weather, thermal and acoustic performance.

Key Features

  • Commercially designed to suit 76mm and 101.6mm
  • Developed specifically for multi-storey residential, schools and architecturally designed housing
  • 4mm up to 10.38mm monolithic glass and up to 18mm double glazed units
  • Superior thermal and acoustic performance (refer to test reports)
  • Superior weather performance
  • Minimal processing, cost effective and simple fabrication

Technical Specifications

Frame Dimensions
Option 1 76 x 35mm
Option 2 101.6 x 44.5mm
Maximum Recommended Sizes
Height 1600mm
Width 1200mm
Weight 50kg
Maximum Product Performance
SLS (Pa) 2000
ULS (Pa) 6000
Water (Pa) 600
Thermal Performance
Uw range SG 4.7 – 6.6
SHGC range SG 0.28 – 0.69
Uw range DG 3.2 – 4.4
SHGC range DG 0.16 – 0.6
Acoustic Performance
Glass Type Rw (C; Ctr) dB
6.38mm Laminate 31 (-0,-2)
10.38mm/ 12/ 6.38mm IGU 34 (-1,-3) (10.38mm lam)
Glazing Details
Single Glazed 4 – 10.38mm
Double Glazed 18
