Framed Double Hung

Framed Double Hung

The EvoPlus Double Hung Window offers a first-rate level of design by allowing the integration with commercial frames ecoFRAMEplus 101.6mm and McArthur Evo 101.6mm, to cater for a wide range of residential and commercial applications. The EvoPlus Double Hung Window offers the flexibility of single and double glazing options. The EvoPlus Double Hung Window integrates a number of design initiatives unique to Alspec® such as the proprietary locking and drainage systems. Developed specifically for multi-storey use and architecturally designed housing EvoPlus Double Hung Window windows offer a superior finish.

Key Features

  • Commercially designed to suit 101.6mm
  • Developed specifically for multi-storey residential, schools and architecturally designed housing
  • 4mm up to 10.38mm monolithic glass and up to 18.5mm double glazed units
  • Superior weather performance
  • Minimal processing, cost effective and simple fabrication

Technical Specifications

Frame Dimensions
Option 1 101.6mm x 44.5mm (W x H)
Option 2 101.6mm x 50mm (W x H)
Maximum Recommended Sizes
Max Sash Height 1090mm
Max Sash Width 1200mm
Max Sash Weight 20kg
Maximum Product Performance
SLS (Pa) 1000
ULS (Pa) 5000
Water (Pa) 300
Thermal Performance
Uw range SG 4.9 – 6.4
SHGC range SG 0.31 – 0.57
Uw range DG 3.7 – 4.5
SHGC range DG 0.22 – 0.53
Glazing Details
Single Glazed(mm) 4 – 10.38mm
Double Glazed(mm) 17.5 – 18.5mm
